PS-21 – Power Slip
Location: Houston, Texas
Used – “As Is Where Is”
Main Body Assembly only. Unit can be rebuilt with OEM, COC.
No Inserts
-
37-1/2″ rotary size
-
2-3/8″ through 14″ size range for all tubulars
-
500 ton load rating
-
45,000 ft-lbs maximum torque
-
10 tons power down force generated to assist with tubular backup
-
Optional hand slip bowls available
-
2500 psi, 10 GPM flow rate hydraulic requirements
Description
Used – “As Is Where Is”
Main Body Assembly only. Unit can be rebuilt with OEM, COC.
No Inserts
Location: Houston, Texas
Enhanced Safety:
- Installs flush with the drill floor, eliminating work platforms during casing running operations so your crew does not have to work from an unsafe elevation
- Gives your crew more room on the drill floor
- Controlled via control panel, which can be located in the driller’s console or stand alone
Improved Efficiency and Versatility:
- Available in all rotary configurations
- Handles all tubulars from 2-3/8″ through 14″
- Can change slips quickly and insert carriers in less than five minutes for added time savings
Insert Carriers Make This a Universal Tool, Not Just Another Power Slip:
- Can trip an entire string through quick changeovers from BHAs to collars to drill pipe
- Can change insert carriers with pipe in the hole for added convenience
- Eliminates loose pieces such as bolts and pins using a special “drop and lock, pull and release” design
- Can be fitted with insert bowls should it become necessary to use hand slips
Centering Device:
- Equipped with a centering device in the top cover that centers pipe so slips can establish safe firm grasp
Slip Set-back:
- Allows tool joints, BHAs, casing centralizers and drill pipe protectors to pass through without dragging on the inserts to help preserve equipment
-
37-1/2″ rotary size
-
2-3/8″ through 14″ size range for all tubulars
-
500 ton load rating
-
45,000 ft-lbs maximum torque
-
10 tons power down force generated to assist with tubular backup
-
Optional hand slip bowls available
-
2500 psi, 10 GPM flow rate hydraulic requirements
